Steel Frame Glass Hinge Doors - Galvanised FPS50 Profile - Zen Doors

$3,960.00
Tax included. Shipping calculated at checkout.
TESTED & ACCREDITED TO AUSTRALIAN/NEW ZEALAND STANDARD –
AS2047-2014 WINDOWS AND EXTERNAL GLAZED DOORS IN BUILDINGS

We have performed the following tests to meet AS2047-2014 Windows and External Glazed Doors in Buildings and can provide a Certificate of Compliance:
  1. Deflection / Span Ratio AS/NZS 4420.1-2016 section 3
  2. Operating Force AS/NZS 4420.1-2016 section 4
  3. Air Infiltration at ±75 Pa AS/NZS 4420.1-2016 section 5
  4. Water Penetration AS/NZS 4420.1-2016 section 6
  5. Ultimate Strength Test AS/NZS 4420.1-2016 section 7
  • PRICE INCLUDES STEEL DOOR JAMB, HANDLES, ROLLER CATCHES, FLUSH BOLTS, SEALS, SINGLE TOUGHENED GLAZING
  • IMAGE SHOWN IS JUST FOR REFERENCE FOR PRICE ESTIMATE PLEASE SELECT THE CLOSEST SIZE FROM THE DROP DOWN MENU
  • PRICE INCLUDES GST
  • ALL DOORS CUSTOM MADE NO STANDARD SIZES

Design and glass options are completely flexible, if you have seen something you like please send it to us and we can price it.

Features & Benefits
  • Tested & Accredited to AS2047-2014 Windows and External Glazed Doors in Buildings, with accompanying Certificate of Compliance to meet Occupancy Permit requirements and BASIX requirement
  • Modern Architectural Design
  • Custom Hand Made Construction for Durable Functionality
  • Built from High Quality Galvanised Steel Tube Profile
  • Fluorocarbon Coating better than Powdercoating
  • Steel Door Jamb Included for Extra Strength and Longevity
  • Single Glazed Toughened Safety Glass included in price ( Clear, Rainstorm, Hammered, Aquatex, Reeded (Fluted), Course Linen, Pinhead, AGC Low-E)
  • High Quality Lever Handles with Spring Latch or Custom Steel Pull Handles with Roller Catches Included in price
  • Flush bolts for double doors included
  • Weather seals included
  • Designed to Impress and Built to Last
  • Orders Made from June 2023 - *5 Year Warranty - Must comply with our installation requirements.

Specifications

  • Zen Steel Hinge Doors & Windows
  • Use: Internal or External
  • Door Design: Custom
  • Material: Precision cold formed galvanised steel profiles - ”P” profile design
  • 3.2mm wall thickness tube with foam injected - Very compact profiles with minimal depth and sight-lines
  • Surface treatment: Zinc-magnesium pre-coating for corrosion protection
  • Gritblasting SA 2.5;
  • The 1st layer is a sealing primer
  • The 2nd layer is a high-durable top coating;
  • Total thickness is at least 150-180 microns according to VMRG quality requirements.
  • Paint: 4FC (Fluorocarbon) (DAIKIN of Japan)
  • Colour: Standard Finishes or Large Range of RAL Powder Coat colours at extra cost, https://www.ralcolorchart.com/
  • Door Jamb: 25/30/40/50mm x 50/75/100mm+
  • Door Frame: 30mm x 50mm
  • Glass Type: Clear, Rainstorm, Hammered, Aquatex, Reeded (Fluted), Course Linen, Pinhead, AGC Low-E
  • Glass Thickness: 5/8/10mm single glazed toughened safety glass
  • TDL: 20T
  • Beads: CTM20
  • Door Type: Hinge
  • Window Type: Fixed, Awning, Casement
  • Hinges: Heavy Duty Welded, 180 degree
  • Mounting Type: Holes Inside of Jamb or Mounting Tabs Outside of Jamb
  • Open way (entering): In-swing or Out-swing left/right
  • Handles: SEMAR matt black lever with spring latch or Custom Pull with Roller Catch
  • Lock: Yes/No (Standard deadbolt or Mortice Lock extra cost)
  • Roller Catch: Yes
  • Flushbolt: Yes
  • Door Sill: Yes/No
  • Rubber Drop Seal: Yes/No
  • Package: 5 Layers of packing, plastic film, soft foam sheet, corrugated paper board, bubble wrap and Wooded Sealed Box
  • CAD Design Drawing: Yes

NOTE: Total Door Frame and Sidelight Windows can be custom made to any size you need, please contact us if you require highlight/sidelight windows and need a more customised estimate.

NOTE: External Doors and Windows can be supplied glazed or un-glazed depending on your building surveyor/certifier.

Get A Quote
